1mm Resolution Ultrasonic Level Meters PTFE Shell Ultrasonic Level Transmitter

  • 1
  • 2

Brand Name : VOTESEN

Model Number : VLS730T

Certification : Industrial

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 35000 Pcs per Day

Delivery Time : 7-25 Working Days

Packaging Details : Carton Box

Measuring Range : 0~1M/0~5M/0~10M/0~15M/0~20M/0~30M/0~40M (Optional)

Accuracy : ±0.1%F.S ~ ±0.3%F.S (According to Different Measuring Range)

Application : Various Fields Concerning Level Measuring and Monitoring

Blind Area : <0.06~2M (According to Different Measuring Range and Sensor)

Display : N/A

Resolution : 1 mm

Protection Level : IP65 (Customizable)

Explosion-Proof Grade : EXiaII BT4Ga (Optional)

Working Environment : -10℃～60℃/110℃ (Customizable)

Temperature Compensation : Automatic Temperature Compensation

Output Signal : Analog, Digital, Switch, and Wireless Transmission (Optional)

Power Supply : DC12~24V (Customizable)

Sensor Dimensions : According to Different Measuring Range and Application scenario

Shell Material : ABS, PP, PTFE, 304, PVDF, Nylon, Cast Aluminum (According to Different Sensor Type)

Installation Method : Thread Mounting (Customizable)

OEM : Acceptable

Package : Standard Export Packages

Warranty : 1 Year

Contact Now

Votesen VLS730T Low Cost Ultrasonic Level Meter Transmitter

Votesen VLS730T Low Cost Ultrasonic Level Meter Transmitter is mainly used to measure liquid level and material level. It has a compact appearance and a sturdy shell, which can be used in different working conditions. Compared with an integrative ultrasonic level meter, it has a lower cost.

PRODUCT PARAMETER

Our Votesen VLS730T Low-Cost Ultrasonic Level Meter Transmitter is manufactured with an engineering waterproof case and a high-quality multi-layer PCB board, designed with a modular circuit.

VLS730T Low Cost Ultrasonic Level Meter Transmitter
Performance Index (Select upon Purchase)
Measuring Range 1M,2M,3M,5M,8M,10M,12M,15M,20M,25M,30M ,35M,40M
Blind Area <0.06~2M (According to Different Measuring Range and Sensor)
Minimum Display Resolution 1MM
Accuracy Rate ±0.1%F.S ~ ±0.3%F.S (According to Different Measuring Range)
Temperature Compensation Automatic Temperature Compensation
Display N/A
On-Site Setting Complete Through the Keys of the Machine
Calibration Factory Calibration, On-Site Calibration
Output Signal (Select upon Purchase)
Analog Output 4～20mA,0～20mA,0～5V,0～10V
Digital Output RS485/Modbus,HART(Two-Wire System)
Switch Output NPN (with PP pulse output option) ,Relay (AC:5A/250V DC:10A/24V)
Wireless Transmission GPRS, LORA, NB, RF, Bluetooth, Wifi, etc.
Power Supply (Select upon Purchase)
Working Voltage DC12~24V (Customizable)
Power Consumption <1.5W
Environmental Performance (Select upon Purchase)
Protection Level IP65 (Customizable)
Explosion-Proof Grade EXiaII BT4Ga (Optional)
Working Environment -10℃～60℃/110℃ (Customizable)
Storage Humidity ≤80%RH Without Condensation
Physical Properties (Select upon Purchase)
Dimensions According to Different Measuring Range and Application scenario
Shell Material ABS, PP, PTFE, 304, PVDF, Nylon, Cast Aluminum (According to Different Sensor Type)
Incoming Cable Customizable (According to Actual Application Requirements)
Installation Thread Mounting (Customizable)
Keyboard Three-Digit Patch A.B.C Key

PRODUCT FEATURE

Our Votesen VLS730T Low Cost Ultrasonic Level Meter Transmitter has the characteristics of safety, cleanliness, high precision, long life, stability and reliability, convenient installation and maintenance, convenient use, and convenient reading.

★ Low Cost

★ High Precision

★ Reliability

★ Safety

★ High Degree of Protection

★ Low Failure Rate

★ Easy To Install

★ Easy To Maintain

PRODUCT APPLICATION

Our Votesen VLS730T Low Cost Ultrasonic Level Meter Transmitter can meet most liquid level and material level measurement requirements without contacting industrial media. It is applicable to various fields concerning level measuring and monitoring:

★ Water Treatment

★ Fire Water Pond

★ Factory Water Tank

★ Solid Level Measurement

HOW TO ORDER?

We can customize your Ultrasonic Level Meter products according to your demand. We produce all kinds of special requirements of Integrative and Segregated ultrasonic level meters and provide OEM and technical support. If you are unsure of the type of ultrasonic level meter or assembly that fits your requirements, kindly provide us the following information for custom made ultrasonic level meter:

★ Ultrasonic Level Meter Type

★ Measurement Medium

★ Measurement Range

★ Working Environment Temperature

★ Cable Length

★ Output

★ Power Supply

★ Accuracy

★ Protection

★ Sample Order Quantity

★ Bulk Order Quantity

If there is a specific request or custom made, you are welcome to provide us your detailed drawing. Feel free to connect with us!
